Flanged Well Seal, Dual Ext.

Flanged Well Seal, Dual Ext.

The Flanged-Type Dual Extraction Well Seal is designed to mount to the top of an flanged well to accommodate a 2” or 3” well head with ports & fittings for the air supply, exhaust and discharge for the pump tubing. It is also equipped with (2) ¼”-20 screws for any type of air/filter regulator mounting bracket and a ½” port which comes plugged for well monitoring / dipping.

Part Number 2000061 – Well Seal, 6” Flange, Dual Ext., Pass Thru

Files

Bill of Material, Exploded View

Alternate Assemblies
  • Part Number 2000064 – Well Seal, 6” SS, Flange, Dual Ext., Hi-Temp, Barbed
  • Part Number 2000066 – Well Seal, 6” Flange, Dual Ext.,Barbed
  • Part Number 2000075 – Well Seal, 8” Flange, Dual Ext., Pass Thru
  • Part Number 2000076 – Well Seal, 8” Flange, Dual Ext., Barbed
  • Part Number 2000241 – Well Seal, 12” Flange, Dual Ext., Pass Thru
  • Part Number 2000297 – Well Seal, 6” Flange, SS Manifold, Dual Ext.

* All BOM’s are available upon request *

BILL OF MATERIAL
3000021
ITEM NO.PART NO.DESCRIPTIONQTY.
11000380FERNCO, 4" X 2", COUPLING 1
21000381NIPPLE, 4", PVC, SCH 801
31000367PLUG, 3/4" PVC1
41000373PASS THRU, 1/2" OD, AIR IN 1
51000378CAP SCREW, 1/4"-20 X 3/8" BUTTON SOCKET 2
61000389FLANGE, 8" CORE, DUAL EXTRACTION, PASS THRUS1
71000374EYE BOLT, 1/4"-20 X 4, S1
81000377NUT, HEX, 1/4, SS2
91000376WASHER, LOCK, 1/4, SS2
101000375WASHER, FLAT, 1/4" NEOPRENE BONDED, SS2
111000366PASS THRU, 1" OD, DISCHARGE1
121000372PASS THRU, 5/8" OD, EXHAUST1
